接收机Receiver

     频率范围/ Frequency Range : 500MHz- -800MHz

     接收灵敏度/ Sensitivity : -94dBm for 30dB

     镜像抑制/ Image Rejection : >60dB

     频率稳定/ Frequency Stability:土0.005%

     调制方式/ Modulation Mode : FM

     最大频偏/ Maximum deviation range:土45KHz

     音频响应/ Audio Frequency Response : 50Hz- 18KHz(土3dB)

     信噪比/ S/N Ratio: >105dB

     动态范围/ Audio Dynamic Range: >100dB

     系统失真/ T.H.D: <0.5%

     工作温度/ Operating Temperature: - 10℃-55℃

     供电/ Power Supply: 12-18V DC500mA

发射机Transmitter

     频率范围/ Frequency Range : 500MHz-800MHz

     发射功率/ Transmitter Power : 10mW

     频率响应/ Frequency Response : 50- 18KHz

     供电/ Power Supply :2x1.5V AA battery

     重量/ Weight : about 400g

     材质/ Material : metal

     尺寸/ Sensitivity : about 270(long) X 50(diameter) mm

标准配置Standard Packing

     接收机/ Receiver: 1 PCS

     发射机/ Transmitter :2 PCS

     电源适配器/ Power Adaptor: 1 PCS

     过机线/ Audio Cable: 1 PCS

     电池/ Battery: 4 PCS

     说明书/ Manual: 1 PCS
